Isokern Magnum 60" Wood Burning Fireplace - 82060

The Isokern Magnum 60" Wood Burning Fireplace commands attention with its impressive size and radiant performance. Built from modular volcanic pumice components, this fireplace brings together authentic masonry craftsmanship and modern prefabrication convenience. Ideal for expansive living areas or outdoor retreats, the Magnum 60" delivers both elegance and efficient heat output—making it a centerpiece for any luxury space.

Features

• Constructed from genuine volcanic pumice for superior insulation and thermal efficiency
• Modular, interlocking design for quick installation and long-term reliability
• Designed for both indoor and outdoor applications
• Compatible with wood-burning or gas log configurations
• Accepts Isoflames, 3-Burner, or Jumbo Slimline gas systems
• Works with decorative log sets: Arizona Weathered Oak, Charred Oak, Driftwood, Birch, Juniper, or Aspen
• Certified to UL 127 and UL 103HT residential safety standards
• Supports GreenTech™ catalytic combustor for cleaner, more efficient burning
• Optional Fire-Lite stand available for installations over combustible floors
• Backed by Earthcore’s limited lifetime warranty

Dimensions & Specifications

• Model: Magnum 60"
• Firebox Opening (Front × Height): 60" W × 36" H
• Rear Width: 48"
• Depth: 28"
• Assembled Height: 92"
• Dry Weight: ~2,500 lbs
• Flue Opening: 18" × 18"
• Minimum Chimney Height: 18 ft (straight) or 21 ft (offset)
• Framing Dimensions: 78" W × 42" D × 98" H
• Hearth Extension: 30" front, 12" each side minimum
• Clearances to Combustibles: 2" sides, 4" rear, 12" above opening
• Firebrick: 1¼" thick standard with 4" thick side-wall bricks required
• Foundation: Non-combustible base required to support full system weight
• Installation Type: Indoor or outdoor with appropriate venting and waterproofing

What’s Included

• Modular pumice components (base plate, sidewalls, backwall, smoke dome, and top plate)
• Mortar and adhesive set
• Flue starter section
• Assembly and installation manual
• Optional: Fire-Lite stand, catalytic combustor, or gas conversion kit

Firebrick Patterns & Usage

Available in two traditional designs:

Running Bond Pattern
160 full or split bricks
320 soapstone equivalents

Herringbone Pattern
192 full or split bricks
384 soapstone equivalents

Installation Notes:
Use 4" thick firebrick on side walls (required for Magnum 60" & 72").
Add 60 extra full or split bricks when using a running bond pattern.
Use full (2½" thick) firebrick for floor and back wall.
Always install with Isoset Firebrick Mortar (ISO-SET-BRICK).

Gas Burner Options

Compatible gas systems for the Magnum Series include:

• Isoflames Stadium Burners – 24” or 36” (NG: ISF-SB24-SN / ISF-SB36-SN, LP: ISF-SB24-SP / ISF-SB36-SP). Requires Isoflames Valve Control Assembly (E-VKN / E-VKP). Compatible with AZ Weathered Oak or Birch log sets.
• Vented 3-Burner Systems – 24”, 30”, 36” (3BRN-24-N/P-MVKEI/R, etc.). Includes battery ignition, remote, and LP conversion kit. Outdoor stainless-steel versions also available.
• Jumbo Slimline Burners (for Magnum only) – 36”, 48”, or 60” NG with electronic ignition and remote (JSLBRN36-N/P-MVKEI/R, JSLBRN48-N/P-MVKEI/R, JUMBOSLIMBRNR-60). Stainless versions for indoor/outdoor use. Match with Jumbo Slimline Log Sets (JUMBOSLIMAWO36LOGS, JUMBOSLIMAWO48LOGS, JUMBOSLIMAWO60LOGS).
• See-Thru Burners (Indoor Only) – 24”–60” NG (2BRN-ST Series). Compatible with matching see-thru log sets (AWOST Series).

Venting System

The Magnum 60" supports all Isokern venting systems:

• Isokern DM Chimney System: Traditional double-wall masonry vent for long-term durability.
• Eco-Steel Chimney System: Lightweight stainless venting for compact framing or reduced clearances.
• Eco-Steel+ System: Enhanced insulation for high-efficiency indoor performance.

Minimum chimney height: 18 ft (straight) or 21 ft (offset).
Top-mounted termination cap or decorative chimney pot recommended for outdoor installations.

Optional Accessories

• Magnum Metal Stand (FLK-60 Fire-Lite Kit) with cement board and base plate
• GreenTech™ Catalytic Combustor Kit (M-CCBSF)
• Isoflames electronic ignition valve kit (E-VKN / E-VKP)
• Assorted log sets (AZ Weathered Oak, Charred Oak, Driftwood, Birch, Aspen, Juniper)
